Technical Specifications:

• Stereo Output Power (8Ω): 4 x 1000W
• Stereo Output Power (4Ω): 4 x 1600W
• Bridge Mono Output (8Ω): 2400W
• Output Circuit: Class H
• Frequency Response: 10Hz – 30KHz ±1dB
• Input Sensitivity: 0.775V / 1.0V / 1.4V
• Input Impedance: 20kΩ (Balanced) / 10kΩ (Unbalanced)
• Crosstalk Between Channels: ≥65dB @ 8Ω 1KHz
• S/N Ratio: ≥105dB
• Damping Factor: ≥400
• THD+N: <0.05% @ 8Ω, 1/10Po
• Slew Rate: 25V/uS
• Height: 2U
• Protection: High/Low Automatism Control, Power Buffering, Short Circuit, Over Loading, Over Heat
